VISION
LCD VIDEO WALLS

The VISION LCD Video Wall  offers an all in one solution for dynamic digital signage, each LCD Video Wall panel comes with integrated software allowing each panel to link without the need for an additional controller. These easy to configure video wall panels come with super slim bezel widths as low as 0.88mm for overall bezel size. As standard the VISION Video Wall panel will have an overall bezel width of 3.50mm; upgrading to a 0.88mm bezel is available if required.

Both the 0.88mm and 3.50mm create super thin bezel widths which means the seams between each video wall panel are almost completely invisible. This close to seamless nature allows for a much a higher picture quality with reduced disruption to the seams.

LCD Video Wall Bezel widths:


0.88mm LCD Video Wall panel

3.50mm LCD Video Wall panel

Icon for LCD Video Wall Bezel Width

ULTRA SLIM BEZEL

Our smallest bezel size is 0.44mm and an overall panel to panel seam of 0.88mm.

LCD Video Wall 16:9 Aspect Ratio

ASPECT RATIO

Each LCD Video Wall panel is a 16:9 aspect ratio, this allows large 16:9 screens to be created with ease, delivering full HD image quality.

LCD Video Wall 500nits brightness

500 CD/M2
Standard LCD video walls have a 500 cd/m2 brightness, perfect most indoor environments.

LCD Video Wall - Modular

MODULAR
The LCD Video Wall panels can be configured to create custom screen sizes, common orientations include 2x2  and 3x3 set ups..

High Resolution LCD Video Wall

HIGH RESOLUTION
The 55" LCD panels have a 1920 x 1080p resolution. A definition level which is extremely hard to achieve with LED.

Warranty for LCD Video Walls

WARRANTY
Our LCD Screen comes with 1 - 2 years warranty as standard.

ENDLESS CONFIGURATIONS

LCD Video Wall Panels 2 x 2

2 X 2
110"

LCD Video Wall Panels 3 x 2

3 X 2
153"

LCD Video Wall Panels 3 x 3

3 X 3
165"

INTERACTIVE VIDEO WALLS

The VISION LCD Video Walls can be combined with an ALPHA IR Touch frames up to 30ft x 10ft to create truly stunning interactive screens on a large scale.

LCD Video Wall Panel with IR Touch

SPECIFICATIONS

SCREN SIZE
MAX RESOLUTION
ASPECT RATIO
BRIGHTNESS
CONTRAST RATIO
VIEWING ANGLE
DISPLAY COLORS
RESPONSE TIME
STANDARD BEZEL WIDTHS

55"
1920 X 1080
16:9
500 cd/m2
3000:1
178°(h) / 178°(v)
16.7m
8ms
0.88mm/3.5mm

DISPLAY

HDMI

VGA

DVI

CVBS

RS232

ON/OFF

1 input
1 input
1 input
1 input & 1 output
1 input & 2 output
1 switch

INTERFACE

COLOR
WALL MOUNT
PANEL MATERIAL
INSTALLATION

Matte Black
VESA (609 x 420mm)
Steel
Wall-mounted

APPEARENCE

MAINS POWER
CONSUMPTION

AC 100 - 240V, 50 - 60Hz
300W

POWER

SIZE
WEIGHT

47.65" X 26.81" X 4.25"
84lbs

DIMENSIONS & WEIGHT

CERTIFICATIONS

CE, FC, ROHS, HDMI

OTHER
